Liner

Our flexible liners are the basis for a self-supporting piping system, that can handle both dimensional changes and 90° bends with an absolute minimum of wrinkles. Combined with our Houseliner Resin the new sewer pipes will get a predetermined wall thickness of your choice. The new pipes are high E-modulus and chemically resistant after curing.The characteristics are much like a new, conventionally made PP sewer pipe.

Houseliner FL and FLT combined with Houseliner Resin are both tested for life expectancy at Eurofins. The test showed that you can expect more then 50% of the initial strength after 50 years of service.

Houseliner FLT gives you a near perfect result. Made for DN50 to DN150, all with the same thickness after curing, approximately 2 mm. Made from 100% PES fiber with a PU coating. Suitable for ambient, hot water or steam curing up to 70°C. Changes in diameter or 90° bends is no match for this liner. This liner is perfect for domestic pipes, or pipes where there is limited demand for ring stiffness. The ease to wet out, combined with low resin usage, gives you more time to install your liner instead of spending time at your wet-out table.

Houseliner FL is your go-to liner. It comes in a variety of sizes and thicknesses to suite your needs. From DN30 all the way to DN400. Wall thickness from 2,5 to 5mm depending on your choice of liner. Made from 100% PES fiber with a TPU coating. Suitable for ambient or hot water curing up to 80°C. Houseliner FL can handle up to 90° bends and changes in diameter. Whatever your needs may be, Houseliner FL can almost for certain fulfill your demands. The wet-out process is extremely fast, giving you more time to invert then spending time at the wet-out table.

Houseliner WO is a round-knitted seamless flexible liner that produces good results for installations through bends and transitions. It is a good complement to the existing assortment. Houseliner WO comes in a variety of sizes from DN50 all the way to DN225. Wall thickness of 3mm. Made from 95% Polyester + 5% Elastane with a TPU coating. Suitable for ambient, UV, steam or hot water curing up to 80°C. Handles up to 90° bends and changes in diameter. It is compatible with Houseliner epoxy resin, UVLCR (Vinyl ester), and UVMA+(Methacrylate). The liner is suitable for ambient, UV, hot water, and steam curing. Installation pressure between approx. 0,4-1,0 bar, curing pressure between approx. 0,4-0,8 bar (depending on dimension of liner and hose pipe)

Benefits

  • Seamless and flexible
  • Handle dimensional changes and 90° bends
  • High quality
  • Documented test results
